OEX Voltage Reducer 24V To 12V - Switch Mode Single Circuit - 10A (With Memory wire for Radio)
Explore the Benefits of the OEX Voltage Reducer 24V To 12V - Switch Mode Single Circuit
| Part No. | ACX7201 |
| Type | VOLTAGE INVERTER / REDUCER |
| Brand | OEX |
| Unit of Measure | EACH |
| Description | OEX Voltage Reducer 24V To 12V - Switch Mode Single Circuit - 10A (With Memory wire for Radio) |
| Warranty | One Year |
| Number of Circuits | 1 |
| Voltage From | 24 |
| Voltage To | 12 |
| Item Type | Switch Mode |
| Continuous Rating | 10A |
| Dimensions | 103 x 120 x 40mm |
| Weight | .66kg |
| Features | • 24V Input, 12V Output10 Amps, 103 x 120 x 40mm • Memory Output Wire (Constant Output for Radios) • Over Voltage & Short Circuit Protection • LED Indicator to Indicate Function of the Unit • High Technology Module Power Conversion provides over 90% Power Efficiency |
| Product Group 1 | AUTO ELEC ACCESSORIES |
| Product Group 2 | VOLTAGE CONTROL |
Efficient Voltage Conversion with OEX Voltage Reducer
The OEX Voltage Reducer 24V To 12V - Switch Mode Single Circuit provides a reliable and efficient solution for lowering voltage from 24 volts to 12 volts. Designed to handle up to 10 amps, this voltage reducer is ideal for automotive and electronic applications that require stable power conversion. It uses advanced switch mode technology that helps reduce power loss and heat generation, ensuring optimal performance over time. This device enables users to convert voltage smoothly while protecting sensitive equipment.
Key Features and Technical Specifications
This OEX voltage reducer supports a single circuit design with a maximum current capacity of 10 amps, perfect for powering radios and other 12V electronics in 24V systems. One significant feature is the included memory wire for radio integration, allowing devices to retain settings after power interruptions. Its compact and lightweight build makes installation straightforward, while the switch mode operation assures energy efficiency and longer device lifespan.
Applications and User Benefits
The OEX Voltage Reducer 24V To 12V - Switch Mode Single Circuit is widely used in vehicles such as trucks, buses, and boats where 24V battery systems are common but 12V devices require safe power supply. The memory wire for radios adds convenience by maintaining preset channels and preferences through power cycles. Users benefit from easy installation, dependable performance, and the reduced risk of electrical faults, making this product a trusted choice for voltage reduction needs.
