OEX BATTERY MASTER ISOLATION SWITCH ONOFF SPST CONTACTS RATED 75A 12V
by OEX
Original price
$46.80
-
Original price
$46.80
Original price
$46.80
-
Original price
$46.80
Original price
Current price
$46.80
$46.80
-
$46.80
Current price
$46.80
| Part No. | ACX3409 |
| Type | BATTERY MASTER SWITCH |
| Brand | OEX |
| Unit of Measure | EACH |
| Description | OEX Battery Master / Isolation Switch On/Off SPST (Contacts Rated 75A @ 12V) |
| Warranty | One Year |
| Number of Speeds | 1 |
| Number of Terminals | 2 |
| Power Rating (Amp) | 75 |
| Switch Action | On - Off - SPST |
| Voltage | 12 |
| Lamp Colour/s | Not Applicable |
| Mount Diameter | 24mm |
| Mount Length | 33mm |
| Note | Replacement Key ACX3422. Terminal Studs 8mm |
| Number of Poles | 1 |
| Number of Positions | 2 |
| Switch Type | Battery Master / Isolation |
| Item Type | Switch |
| Switch Illumination | Non Illuminated |
| Weight | .26kg |
| Features | • 2 Position, On - Off. • Two 8.00mm stud terminals. • Key is removable in Off position. • Panel or recessed mount. • 75amp continuous @ 12volt. • Spare key part no. ACX3422. |
| Product Group 1 | AUTO ELEC ACCESSORIES |
| Product Group 2 | FUSES BREAKERS RELAYS SWITCHES |
