NARVA 4 WAY ROCKER SWITCH PANEL OFFON SPST RED LED CONTACTS RATED 20A 12V
by NARVA
Original price
$247.00
-
Original price
$247.00
Original price
$247.00
$247.00
-
$247.00
Current price
$247.00
| Part No. | 63190 |
| Type | SWITCH MOUNT/ PANEL | Brand | NARVA |
| Unit of Measure | EACH | Description | Narva 4 Way Rocker Switch Panel Off/On SPST Red LED (Contacts Rated 20A @ 12V) |
| Warranty | One Year | Number of Terminals | 3 |
| Power Rating (Amp) | 20 | Switch Action | Off - On |
| Voltage | 12 | Lamp Colour/s | Red |
| Mount Length | 93mm | Number of Poles | 1 |
| Number of Positions | 2 | Switch Type | Rocker |
| Switch Illumination | Illuminated | Weight | 0.33kg |
| Features | • SPST • Amperage rating 20A at 12V, 10A at 24V • Mounting opening: 105 x 93mm • Overall panel dimensions: 130 x 120mm • Includes 4 Off/On switches with red 'On' illumination • 46 piece symbol set for RV and Marine applications included |
Product Group 1 | AUTO ELEC ACCESSORIES |
| Product Group 2 | FUSES BREAKERS RELAYS SWITCHES |
