OEX ROCKER SWITCH ONOFF SPST 12V RED ILLUMINATED CONTACTS RATED 10A 12V
by OEX
Original price
$11.70
-
Original price
$11.70
Original price
$11.70
$11.70
-
$11.70
Current price
$11.70
| Part No. | ACX3787 |
| Type | SWITCH | Brand | OEX |
| Unit of Measure | EACH | Description | OEX Rocker Switch On/Off SPST 12V Red Illuminated (Contacts Rated 10A @ 12V) |
| Warranty | One Year | Number of Terminals | 4 |
| Power Rating (Amp) | 10 | Switch Action | On - Off - SPST |
| Voltage | 12 | Lamp Colour/s | Red |
| Mount Diameter | 20mm | Mount Length | 2mm |
| Note | NOTE: For 24V applications, use Part No. ACX3912 resistor with the switch | Number of Poles | 1 |
| Number of Positions | 2 | Switch Type | Rocker |
| Switch Illumination | Illuminated | Weight | .02kg |
| Features | • 12V • 10A • 1 pole • 2 positions • 4 blade terminals • On/Off - SPST • 20mm round mounting hole |
Product Group 1 | AUTO ELEC ACCESSORIES |
| Product Group 2 | FUSES BREAKERS RELAYS SWITCHES |
