COLE HERSEE CONTINUOUS DUTY SOLENOID 12V 100A NORMALLY OPEN
by COLE HERSEE
Original price
$170.30
-
Original price
$170.30
Original price
$170.30
$170.30
-
$170.30
Current price
$170.30
| Part No. | 24612-10BX |
| Type | SOLENOID SWITCH | Brand | COLE HERSEE |
| Unit of Measure | EACH | Description | Cole Hersee Continuous Duty Solenoid 12V 100A Normally Open |
| Warranty | One Year | Number of Circuits | 1 |
| Power Rating (Amp) | 100 | Thread | 5/16 - 24 |
| Voltage | 12 | Item Type | Continuous Duty |
| Contact Material | Silver Alloy | Solenoid Action | Normally Open |
| Insulated Return | Yes | Features | • 12V • 100 Amp Continuous • 400 Amp Inrush • 100 Amp Make and Break • Normally open • SPST Off / On • Silver contacts • Insulated coil terminal 10-32" • 4 stud, copper stud terminals: 5/16-24" • Glass black nylon housing, F bracket • Plated steel nuts & washers included • Mounting holes 8mm x 15mm, 56mm CTC • Dimensions: H 65 x D 47 x W 76mm |
| Product Group 1 | AUTO ELEC ACCESSORIES | Product Group 2 | FUSES BREAKERS RELAYS SWITCHES |
