COLE HERSEE IGNITION SWITCH 3 POSITION
by COLE HERSEE
Original price
$0
Original price
$262.60
-
Original price
$262.60
Original price
Current price
$262.60
$262.60
-
$262.60
Current price
$262.60
| Part No. | 956-3124BX |
| Type | IGNITION SWITCH |
| Brand | COLE HERSEE |
| Unit of Measure | EACH |
| Description | Cole Hersee Ignition Switch 3 Position |
| Warranty | One Year |
| Number of Terminals | 5 |
| Power Rating (Amp) | 10A @ 12V |
| Switch Action | Off - Ign - Start |
| Voltage | 12 |
| Lamp Colour/s | Not Applicable |
| Mount Diameter | 46mm |
| Mount Length | 78mm |
| Note | 5A Start 10A Acc. 10A Ign |
| Number of Poles | 1 |
| Number of Positions | 3 |
| Switch Type | Ignition |
| Switch Illumination | Non Illuminated |
| Features | • Key removable in “Off” Position Only (where actuator applicable) • Ignition Proof to SAE J259 • 5 screw terminals • Coded lock & keys • Gasket-sealed, Shutter lock seal, O-ring seal in stem • Ground terminal • 1"-24 bushing • Off-Ign/Acc-Ign/Start. Spring return to Ign/Acc. Key removable at Off • Ratings at 12V DC: 10A Accessory, 10A Ignition, 5A Start, 1A Ground |
| Product Group 1 | AUTO ELEC ACCESSORIES |
| Product Group 2 | FUSES BREAKERS RELAYS SWITCHES |
