COLE HERSEE BATTERY MASTER SWITCH DPST ONOFF
by COLE HERSEE
Original price
$0
Original price
$224.90
-
Original price
$224.90
Original price
Current price
$224.90
$224.90
-
$224.90
Current price
$224.90
| Part No. | 75910BX |
| Type | BATTERY MASTER SWITCH |
| Brand | COLE HERSEE |
| Unit of Measure | EACH |
| Description | Cole Hersee Battery Master Switch DPST On/Off |
| Warranty | One Year |
| Number of Terminals | 4 |
| Power Rating (Amp) | 125 |
| Switch Action | On - Off - DPST |
| Voltage | 6-36V |
| Lamp Colour/s | Not Applicable |
| Mount Diameter | 19mm |
| Mount Length | 6mm |
| Note | Lockout options include ACX3417BL, 24505-01BL, 24505-01RBL or 24505-01YBL; Mounting Bracket to suit ACX3405 |
| Number of Poles | 2 |
| Number of Positions | 2 |
| Switch Type | Battery Master / Isolation |
| Switch Illumination | Non Illuminated |
| Features | • DPST On / Off • 125A continuous, 1000A intermittent • 6V-36V multivoltage • 10mm main terminal studs • 4.5mm field terminal studs • Weather resistant, O-ring sealed • Silver contacts • Brass mounting stem and studs • Chrome plated die cast alloy lever • Brass indexing pin prevents rotation • Steel plated casing |
| Product Group 1 | AUTO ELEC ACCESSORIES |
| Product Group 2 | FUSES BREAKERS RELAYS SWITCHES |
